Why buy the Ariens ARROW E 48R 48″ Stand-On Mower (Kit)?
- Fully electric commercial power from four interchangeable 56V 4kWh FusionCore™ lithium-ion batteries.
- QuickSwap battery system enables continuous, all-day cutting capability (conditions dependent).
- Heavy-duty 122cm (48″) fabricated rear-discharge deck made from 4.6mm (7-gauge) steel.
- Ergonomic stand-on design with a foldable, spring-mounted operator platform for versatility and comfort.
- Zero emissions and low noise, perfect for use in restricted or sensitive environments.
- Intuitive controls featuring a colour LED display, ECO mode, and foot-assisted deck height adjustment.
The Ariens ARROW E 48R brings fully electric, commercial-grade performance to the stand-on mower category. Engineered for professionals working in areas where noise and carbon emissions are restricted, this machine combines maximum manoeuvrability with an ergonomic, upright working position that reduces operator fatigue.
All-Day Electric Power with FusionCore™
At the heart of the ARROW E 48R is the Ariens FUSIONCORE™ power system. It utilises four individual, interchangeable 56V, 4kWh lithium-ion batteries, providing a total capacity of 16kWh. This innovative QuickSwap battery system is a market leader, allowing operators to mow all day by simply swapping depleted batteries for fresh ones in seconds. This eliminates downtime and ensures productivity is maintained throughout the working day. The system offers standard charging (11 hours) and fast charging (5.3 hours) options to suit different operational needs.
Robust Commercial Deck and Spindle Design
This mower features a formidable 122cm (48″) fabricated rear discharge deck, welded from strong 4.6mm sheet steel for exceptional durability. The rear discharge design is ideal for municipal use and working alongside paths or flowerbeds, as it prevents clippings from being thrown sideways. The three high-performance brushless spindle motors are equipped with a slip clutch, a patent-pending technology designed to absorb impacts from foreign objects, protecting the motors from damage and ensuring longevity.
Ergonomic Operation and Intuitive Control
The stand-on design offers superior visibility and agility, making it easy to navigate complex landscapes and narrow passages. The spring-mounted driver’s platform is foldable, transforming the ARROW E into a walk-behind mower for tackling slopes up to 20° or working under low-hanging branches. A colour LED display provides real-time information on battery charge status, operating modes, hours, and system diagnostics. An ECO mode is included to conserve energy by reducing blade speed in lighter conditions, extending battery life even further.
Ideal Applications and Accessories
The ARROW E 48R is the perfect choice for professional service providers, municipalities, and grounds maintenance teams managing medium-to-large sized areas, including parks, campuses, and leisure facilities. It excels on flat, undulating, or even hilly terrain. To extend its cutting capability, an additional Lithium-Ion QuickSwap 4 kWh battery is available. For enhanced charging flexibility, an Off board charger kit and a Fast charger w/y harness kit can be sourced.
As an established, authorised UK dealer for Ariens, Sims Garden Machinery has over 100 years of experience. When you purchase from Sims, you are investing in a machine that is fully supported for its lifetime. Our trained sales staff are on hand at our Stratford-upon-Avon showroom to provide expert advice, while our dedicated workshop with its team of trained mechanics ensures your mower receives the best possible after-sales care. For local customers, we provide a comprehensive handover service, including free Pre-Delivery Inspection (PDI), local delivery, and a full demonstration to ensure you are confident in using and maintaining your new machine. We are not just box-shifters; we are your long-term partner in garden and grounds care.
Our team is here to help. Contact us today for expert advice.
Technical Specification
| Model Number | 998304 |
| Drive System | Ariens FUSIONCORE™ brushless electric wheel motors with reduction gear, 2 x 5 kW max. |
| Max. Speed Forward / Backward | 17.7 km/h / 8.9 km/h (11 mph / 5.5 mph) |
| Deck Type | Rear discharge |
| Deck Material | 4.6 mm sheet steel |
| Deck Construction | Welded |
| Deck Lift System | Foot pedal and hand lever |
| Number of blades | 3 |
| Spindle Material | Forged Aluminium |
| Spindles drive | Ariens FUSIONCORE™ direct electric drive brushless, 3x 3.5 kW max. |
| Cutting Width | 122 cm (48″) |
| Cutting Heights | 3.8 cm – 12.7 cm (1.5″ – 5.0″) |
| Cutting Positions | 15 |
| Front Wheels | 13 x 6.5-6 semi-pneumatic |
| Rear Wheels (inch) | 20 x 10-10 |
| Driver Platform | Suspended, foldable |
| LED Interface w/ Hour Counter & 2 USB Charging Sockets | Yes |
| Weight | 545 kg |
| Length | 190 cm |
| Width | 127 cm |
| Height | 117 cm |
| Limited Warranty Machine | 5 years / 1,500 hours, no hour limit in the first 2 years |
| Warranty Battery (Years) | 3 |
| Battery Type | 56V Ariens FUSSIONCORE™ Li-Ion swappable |
| Battery Capacity | 4 x 4 kWh |
| Number of Batteries | 4 quick-change |
| Charge Time | Fast charging: 5.3 hrs.; standard charging: 11 hrs. |
Why buy from Sims Garden Machinery?
Authorised main dealer
We are authorised dealers for leading brands, meaning genuine parts, manufacturer-approved training, and warranty support you can rely on.
Real people, real support
No call centres. No ticket systems. Just a knowledgeable local team you can speak to when you need help.
Expert advice — not pushy sales
Our team are trained mechanics and product specialists, so you get honest, practical advice based on how you’ll actually use the machine.
Established, independent family business
We’re a long-standing independent dealer with deep roots in the local area — built on reputation, repeat customers, and word of mouth.
Frequently Asked Questions
Frequently Asked Questions
Who is the Ariens ARROW E 48R designed for?
The ARROW E 48R is a fully commercial machine designed for professional users such as landscape contractors, municipalities, and grounds maintenance teams. Its zero-emission, low-noise operation makes it particularly suitable for working in sensitive areas like schools, hospitals, parks, and residential complexes where disturbance must be minimised.
How does the QuickSwap battery system work?
The mower is powered by four 56V, 4kWh FusionCore™ batteries. The QuickSwap system allows the operator to easily remove depleted batteries and replace them with fully charged ones in just a few seconds. This means that with a second set of batteries on charge, the mower can run continuously throughout the day without long downtimes for recharging the machine itself.
What are the advantages of a stand-on mower over a traditional zero-turn?
Stand-on mowers offer several advantages. They are typically more compact, making them easier to transport and store. The standing position provides excellent visibility around the machine and over the cutting deck. It also allows the operator to easily shift their weight for better stability on slopes and absorb bumps with their legs, reducing body fatigue. Finally, getting on and off is much quicker, which is a significant time-saver when moving obstacles or working across multiple small areas.
What is the benefit of the rear-discharge deck?
A rear-discharge deck ejects grass clippings from the back of the mower, between the wheels. This is advantageous because it doesn’t throw debris onto paths, driveways, or into flowerbeds, reducing clean-up time. It also allows for trimming effectively on either side of the deck without worrying about the discharge chute’s position.
Does this mower come with everything needed to start mowing?
Yes, the Ariens ARROW E 48R is supplied as a kit that includes the mower itself and the four 4kWh FusionCore™ batteries required for operation. A charger is also included. For continuous all-day mowing, purchasing an additional set of batteries and a fast or off-board charger is recommended.
